Gypsum Finish Panel

About Gypsum Finish Panel

Gypsum Finish Panels
THERMOFRIZ offer Gypsum Finish Panels, that are available in gypsum finish and are extensively used in various offices & homes in false celling, in order to reduce the inside temperature of the room. Not only do they make the inside temperature go down considerably, but also assist the air conditioning in being more effective. Our gypsum finish panels are highly durable, long lasting in nature and available with us in all standard shapes and sizes.

Installation Specifications for Walls
Can be installed on GI metal/ Wooden/ MS frame of 50 x 50mm making a grid of 610 x 610mm c/c. The frame is to be made in proper line after leveling. The panels will be backed with 50mm Sentetic Wadding 1000 GSM inserted inside the grid of 610 x 610mm.

Installation Specifications for Ceiling
Can be installed making grid of size 600 x 600mm c/c of G.I pre coated system using Main T 34 x 24 & Cross T 24 x 24 & wall angles suspended suitably by dash fastners, GI wire and suspension clip and MS cleats. A layer of 50mm Sentetic Wadding 1000 GSM to be used over false ceiling for best results.

Technical Specification

Std. Size:	1220mm  610mm; 595mm 595mm
Other Size:	2000mm x 610mm; 1200mm  600mm; 915mm  610mm; 600mm 600mm;
Thickness in mm:	10, 13, 15, 20, 25, 40, 50, 75, 100, 150
Density in kg/cuM:	400, 450, 600, 800

Technical Specifications

Providing and fixing Thermofriz Acoustic Gypsum Finish Panels made from wood fibers mineralized with magnesite composite many thickness and is of multi-colour. Highly recommend for interiors for heat and sound blockage, has excellent sound result as per ISO: 354 -1985 and ASTM 423-90a. Thermofriz wood wool boards are made as per IS: 3308, BS: 1105 & DIN:1101. These board are not easily ignitable for which we have a fire test done under BS: 476 Part 5, 6, 7. Weather Test Cycle (B) IS: 9307 Part 7- 1979. Thermal Conductivity Test under BS: 874-1965.

Effortless Installation and Seamless Finish

These gypsum finish panels are designed for ease of installation via both mechanical and adhesive methods in standard drywall systems. The square edge profile ensures panels fit neatly together, delivering a sleek, smooth finish. Ready to paint straight from the factory, these panels expedite project turnaround times and reduce labor intensity for installers.


Reliable Performance and Versatility

Engineered for durability, the panels offer strong tensile and tear strength, moderate moisture resistance, and low heat conductivity-ideal for a variety of environments. Whether upgrading an office, renovating a home, or designing new spaces, the combination of gypsum and wood wool guarantees sound insulation and fire protection, maintaining a safe and comfortable atmosphere.
